除上述3大主要品牌及产品系列外，艾诺斯集团还提供针对汽车、船舶启动的高性能纯铅技术产品Odyssey系列以及应用于医疗、工业设备等行业的高性能缠绕式纯铅电池Cyclon系列。
|
General Specifications |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
Nominal Capacity (Ah) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
Nominal Dimensions |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
Type |
Nominal Voltage (V) |
10 hr rate to 1.67Vpc |
Length mm |
in |
Widt mm |
h |
Height mm |
in |
kg |
Overall Weight |
lbs |
Torque in-lbs |
Nm |
Internal Resistance (mΩ) |
Typical Short Circuit Current (A) |
|||||||||||||
|
G13EP |
12 |
13 |
175.5 |
6.91 |
83.3 |
3.28 |
129.8 |
5.11 |
4.9 |
10.8 |
50 |
5.6 |
8.5 |
1400 |
||||||||||||||
|
G16EP |
12 |
16 |
181.6 |
7.15 |
76.2 |
3.00 |
167.9 |
6.61 |
6.1 |
13.5 |
50 |
5.6 |
7.5 |
1600 |
||||||||||||||
|
G26EP |
12 |
26 |
166.9 |
6.57 |
175.8 |
6.92 |
126.0 |
4.96 |
10.1 |
22.3 |
60 |
6.8 |
5.0 |
2400 |
||||||||||||||
|
G42EP |
12 |
42 |
197.4 |
7.77 |
165.9 |
6.53 |
170.7 |
6.72 |
14.9 |
32.9 |
60 |
6.8 |
4.5 |
2600 |
||||||||||||||
|
G70EP |
12 |
71 |
330.7 |
13.02 |
168.1 |
6.62 |
176.0 |
6.93 |
24.3 |
53.5 |
60 |
6.8 |
3.5 |
3500 |
||||||||||||||
|
Constant Current Discharge Performance |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||
|
Constant current discharge rate, amps to 10.02V at 25?C (77°F) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||
|
|
Minutes |
|
|
|
|
Hours |
|
|||||||||||||||||||||
|
Battery |
5 |
10 |
|
15 |
30 |
1 |
5 |
8 |
10 |
20 |
||||||||||||||||||
|
G13EP |
70.8 |
43.6 |
|
32.2 |
18.6 |
10.4 |
2.5 |
1.6 |
1.3 |
0.7 |
||||||||||||||||||
|
G16EP |
90.0 |
54.8 |
|
40.1 |
23.0 |
12.7 |
3.0 |
2.0 |
1.6 |
0.8 |
||||||||||||||||||
|
G26EP |
143.4 |
90.7 |
|
67.4 |
39.0 |
21.7 |
5.0 |
3.2 |
2.6 |
1.4 |
||||||||||||||||||
|
G42EP |
212.0 |
138.4 |
|
104.1 |
60.8 |
33.8 |
7.9 |
5.1 |
4.2 |
2.3 |
||||||||||||||||||
|
G70EP |
342.4 |
228.5 |
|
173.4 |
102.5 |
57.4 |
13.4 |
8.7 |
7.1 |
3.9 |
||||||||||||||||||
|
Constant Power Discharge Performance |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||
